Premium Shrink Tunnel
SF-5030LG
SF-5030LG adopts advance bottom circulation air technology, full use of heat to arise energy efficiency. Adjustable blowing direction and volume from bottom side to get a uniform shrinking appearance on the top and bottom of product.
Sales Manager: Mrs. Cecilia Pii
Mobile/WhatsApp/Wechat: +86 189 1774 9969
- SF-5030LG adopts advance bottom circulation air technology, full use of heat to arise energy efficiency. Adjustable blowing direction and volume from bottom side to get a uniform shrinking appearance on the top and bottom of product.
- Visible window shows shrink process inside tunnel, the top of tunnel can be opened for easy clear and maintenance;
- The heating elements are stainless steel which has a long life span and high energy efficiency;
- The use of French Schneider inverter controls transmission speed which has the function of infinitive speed;
- Imported insulation curtain greatly reduces the heat loss;
- The shrink temperature, conveyor speed and air volume are adjustable;
- The conveyor uses new types of rollers covered with durable imported fiber tubes which have the functions of anti-high temperature, wear resistance, non-film damage, non-deforming and long terms using; This machine applies to use POF, PVC, PET shrink film
Technical Parameters:
| ModelĀ Ā Ā Ā Ā Ā Ā Ā Ā Ā | SF-5030LG |
| Power | 16kw |
| Power Supply | AC 380V 3PH 50Hz |
| Tunnel Size LĆWĆH | 1500Ć500Ć300mm |
| Packing Speed | 0-15m/min |
| Air Temperature | 0-300ā |
| Table Height | 825Ā±25mm |
| Applicable Shrink Film | POF, PVC, PET |
| Machine Size LĆWĆH | 1860Ć985Ć1315mm |
| Crate Size LĆWĆH | 1910Ć1035Ć1465mm |
| G./N. Weight | 493/453kgs |
